Description
APC by Schneider Electric Easy UPS Double Conversion Online UPS - 3 kVA/2.40 kW - 4U Tower - 4 Hour Recharge - 12.70 Minute Stand-by - 230 V AC Input - 220 V AC, 230 V AC, 240 V AC Output - 6 x IEC 60320 C13, 1 x IEC 60320 C19 - Single Phase - Serial Port
Easy UPS On-Line
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
For small to medium businesses, APC by Schneider Electric delivers a new category of UPSs designed for essential power protection needs even in the most unstable power conditions. APC Easy UPS 1 Ph Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range, inconsistent power conditions and delivering the quality millions of IT professionals trust around the world.
Specifications :
Controls/Indicators
|
Status Indicators |
LED Indicators:
LCD Graphics Display:
Control Panel:
|
Interfaces/Ports
|
Serial Port |
Yes |
|
USB (HID Compliant) Port |
Yes |
Environmental Conditions
|
Maximum Operating Temperature |
40°C |
|
Maximum Operating Elevation |
3 km |
|
Maximum Storage Elevation |
14.76 km |
Management
|
Network Management |
USB |
|
Alarm |
On Battery |
|
Overload |
|
|
Low Battery |
Physical Characteristics
|
Weight (Approximate) |
52 kg |
|
Form Factor |
Tower |
|
Rack Height |
4U |
|
Height |
172 mm |
|
Width |
437 mm |
|
Depth |
632 mm |
Technical Information
|
Application/Usage |
Server |
|
Equipment |
|
|
Business |
|
|
Overload Protection |
Yes |
|
Plug/Connector Type |
IEC 320-C14 |
|
Phase |
Single Phase |
|
Receptacle Type |
IEC 60320 C19 |
|
IEC 60320 C13 |
|
|
Transfer Time |
0 ns |
|
Receptacle Detail |
6 x IEC 60320 C13 |
|
1 x IEC 60320 C19 |
General Information
|
Product Type |
Double Conversion Online UPS |
|
Manufacturer Part Number |
SRV3KRILRK |
|
Manufacturer Website Address |
|
|
Manufacturer |
Schneider Electric SA |
|
Product Name |
Easy UPS 3kVA Tower UPS |
|
Product Line |
Easy UPS |
|
Brand Name |
APC by Schneider Electric |
Battery Information
|
Battery Chemistry |
Lead Acid |
|
Battery Energy |
3380.4 kJ |
|
Number of Batteries |
1 |
|
Backup/Run Time (Half Load) |
30.10 Minute |
|
Backup/Run Time (Full Load) |
12.70 Minute |
|
Battery Characteristics |
Maintenance-free, Sealed, Leak-proof |
|
Replaceable Battery |
Yes |
|
Typical Battery Recharge Time |
4 Hour |
Power Description
|
Input Voltage |
230 V AC |
|
Output Voltage |
230 V AC |
|
240 V AC |
|
|
220 V AC |
|
|
Surge Energy Rating |
600 J |
|
Waveform Type |
Sine Wave |
|
Input Voltage Range |
160 V AC - 280 V AC |
|
Output Frequency |
60 Hz |
|
Input Frequency |
70 Hz |
