Description
The Datalogic QuickScan QW2520 USB Barcode Scanner Kit is the entry-level corded imager that outperforms expectations with high-speed, reliable 2D scanning at the point of sale. Whether you’re scanning standard retail barcodes, mobile coupons, or damaged and low-quality labels, the QW2520 delivers fast and accurate performance with every trigger pull.
Designed for comfort and built to last, this rugged imager fits naturally in the hand and offers tactile, audio, and visual feedback — including Datalogic’s patented Green Spot technology — to confirm successful scans. With Motionix™ technology, the device wakes instantly when picked up, enhancing workflow efficiency.
Optimised for the retail environment but equally at home in hospitality, healthcare, or government sectors, the QuickScan QW2520 handles barcodes through plexiglass and reads from screens or paper. With IP52 protection, drop resistance up to 1.5 m, and a scan trigger rated for over 10 million actuations, this barcode scanner is a durable, high-performance solution for your business.
Product Features
-
Superior 2D Scanning Performance – Reads 1D, 2D, postal, composite, and DotCodes
-
Robust & Reliable – Survives multiple 1.5 m drops and over 10 million trigger pulls
-
USB Kit Included – Plug-and-play setup with USB cable included
-
Omni-Directional Scanning – No need to align barcode orientation
-
Green Spot Feedback – Visual confirmation of successful scans
-
Reads Through Plexiglass – Ideal for COVID-compliant barriers
-
Bright Dual-Blue Aimer – Easy and precise barcode targeting
-
Motionix Technology – Auto-wake for immediate scanning on pickup
-
Ergonomic & Lightweight – Comfortable for all-day use at just 145g
-
Versatile Usage – Ideal for retail, government, healthcare, and light industry
Product Specifications
Scan Technology | Solid-state linear imager (1 MP) |
Scanning Capability | 1D, 2D, PDF417, DotCodes, postal, composite |
Scan Pattern | Linear, omni-directional |
Host Interface | USB |
Cable Included | USB Cable (Kit) |
Motion Tolerance | Up to 762 mm/s |
Scan Distance | Up to 398.78 mm |
Minimum Print Contrast | 15>% |
Image Formats | BMP, JPEG, TIFF |
Feedback Indicators | Green Spot, LED, Buzzer |
Ingress Protection | IP52 |
Drop Resistance | 1.5 m / 5 ft onto concrete |
Operating Temperature | 0°C to 50°C |
Storage Temperature | -40°C to 70°C |
Weight | 145g (approx., excluding cable) |
Dimensions | Approx. 16.3 x 9.1 x 4.1 cm (L x W x H) |
Color | Black |
Use Cases | Retail, Government, Hospitality, Healthcare, Light Industry |
Features
- 52
- Rugged
- Industrial
- Mid Level
- Handheld
- Wired
- USB
- Black
