Description
The FEC PP-9735L is a robust and performance-driven 15-inch touchscreen POS terminal designed for fast-paced retail, hospitality, and service environments. Powered by the Intel® Celeron® J6412 Quad-Core processor, this system combines smooth performance with low power consumption, enabling businesses to operate efficiently even during peak hours.
Equipped with 8GB DDR4 memory and a 128GB M.2 PCIe SSD, the PP-9735L ensures rapid application loading and multitasking. The 1024 x 768 resolution LCD panel with 350-nit brightness and projected capacitive (PCAP) touchscreen offers high visibility and responsive touch performance in both dim and brightly lit conditions.
Designed with a Galaxy Grey aluminium die-cast housing, this model features a single-hinge stand and VESA 100x100 mount compatibility for versatile placement. Integrated dual 2W speakers, multiple USB ports, HDMI, and COM ports provide all the essential connectivity. It supports Windows 10 IoT LTSC, ensuring compatibility with the latest retail software platforms.
With its rugged construction and modern design, the FEC PP-9735L is ideal for retail counters, quick-service restaurants, and any environment demanding reliable, stylish POS functionality.
Product Features
- Intel® Celeron® J6412 Quad-Core Processor up to 2.6 GHz for reliable performance
- 8GB DDR4 RAM (expandable to 32GB) for smooth operation
- 128GB PCIe M.2 SSD ensures fast boot and application speeds
- 15" LCD Touch Display with 350 nits brightness and 1024 x 768 resolution
- PCAP Touchscreen for accurate and responsive multi-touch input
- Durable aluminium die-cast housing with Galaxy Grey finish
- Single-hinge stand and VESA 100x100 compatibility for flexible mounting
- Comprehensive I/O ports: HDMI, Giga LAN, USB 2.0 & 3.0, RJ45 COM ports
- Dual 2W internal speakers for clear audio notifications
- Runs Windows 10 IoT Enterprise 2021 LTSC for long-term reliability
- Optional SMART DD video interface for second display integration.
Product Specifications
Specification | Details |
Model | FEC PP-9735L (Lite) |
Part Number | TTFIPP9735L001 |
Processor | Intel® Celeron® J6412 Quad-Core (up to 2.6 GHz) |
Memory | 8GB DDR4 (1 x SO-DIMM socket, up to 32GB) |
Storage | 128GB PCIe M.2 SSD |
Display | 15" LCD, 1024 x 768 resolution, 350 nits brightness |
Touchscreen | Projected Capacitive (PCAP) |
Graphics Output | 1 x HDMI |
Audio | 2 x 2W internal speakers |
I/O Ports | 3 x USB 2.0, 1 x USB 3.0, 2 x COM (RJ45), 1 x LAN, 1 x SMART DD, 1 x DC-IN |
Mounting | VESA 100 x 100 mm |
Construction | Aluminium Die-Casting, Galaxy Grey housing |
Power Adapter | 65W, 19V DC input |
Operating System | Windows 10 IoT Enterprise LTSC 2021 |
Optional Features | SMART DD for secondary display |
Features
Colour:
- Black
Display:
- Single
Interface:
- HDMI
- USB
Magstripe Option:
- No
OS Compatability:
- Windows 10 IOT
Printer:
- No
Processor:
- Intel Celeron
Ram:
- 8 GB
Scanner Capability:
- No
Screen Size Font:
- 15.6 inch
Storage Capacity:
- 128GB
Storage Type:
- SSD
Terminal Type:
- All-in-one POS
Touch Technology:
Capacitative
Warranty:
1 Year
