Description
The ION F10 Power Board UPS (850VA/490W) is the perfect compact power protection solution for Australian homes and small businesses. Designed to protect your valuable electronics from power surges, outages, and fluctuations, it features six Australian 3-pin outlets – three dedicated to surge protection and three offering both surge and battery backup.
Ideal for POS systems, security setups, home office workstations, modems, routers, storage devices, gaming consoles, and home theatres, the ION F10 ensures uninterrupted operation and reduces the risk of data loss or downtime. With fanless technology for silent operation, auto-restart/auto-charge functions, and an intelligent LED indicator, this UPS delivers reliability and peace of mind.
Backed by a 2-Year Advanced Replacement Warranty, the ION F10 is a trusted and affordable solution for essential power protection in everyday applications.
Product Features
- 850VA/490W simulated sine wave UPS for reliable backup power
- Six Australian 3-pin outlets (3 surge-only, 3 surge + battery backup)
- Compact and wall-mountable design for easy installation
- Fanless technology for silent operation in any environment
- Cold start function for instant power-on during outages
- Auto-restart and auto-charge capability for convenience
- USB communication port for UPS monitoring and control
- RJ-11/RJ-45 protection for telephone and network lines
- Intelligent LED indicators for real-time UPS status updates
- 2-Year Advanced Replacement Warranty
Product Specifications
Category | Details |
Brand | ION |
Model | F10 |
Type | Power Board UPS |
Output Power Capacity | 490W / 850VA |
Max Configurable Power | 490W / 850VA |
Nominal Voltage (Battery Mode) | 220-240V AC |
Frequency (Battery Mode) | 50/60Hz ±1% |
Waveform (Battery Mode) | Simulated Sinewave |
THDv | ≤3% (linear load), ≤5% (non-linear load) |
Transfer Time | 4ms typical |
Overload Protection | Circuit breaker / firmware protection |
Input Voltage Range | 180-270V AC |
Battery Type | 12V, 5.6AH (1x battery) |
Recharge Time (to 90%) | 8 hours |
Charger Current | 0.7A |
Display | LED |
Communication Ports | USB, RJ-11/RJ-45 |
Alarms | Battery mode, low battery, overload, fault |
Physical Dimensions | 90mm × 110mm × 309mm |
Weight | 3kg |
Operating Temperature | 0–40°C |
Humidity Tolerance | 0–90% non-condensing |
Approvals | CE |
Warranty | 2-Year Advanced Replacement |
