Description
The POSIFLEX TM3110 9.7" PCAP Touch Monitor (PFTM3110CB-U) is a sleek and compact secondary display solution designed for retail, hospitality, and POS environments. With its bezel-free capacitive touch panel and 1024x768 resolution, it delivers precise touch performance and crystal-clear visuals.
Built with a slim, modern design, the TM3110 is ideal for customer-facing or operator applications. It features USB connectivity for touch input and VGA interface for video, offering flexibility and simple installation. The front IP65 rating ensures protection against dust and liquid spills, making it suitable for high-traffic checkout areas. Whether used as a primary touch interface or a customer interaction screen, the TM3110 offers exceptional durability, responsive performance, and reliability—hallmarks of POSIFLEX design.
Product Features
- 9.7" TFT LCD panel with 1024x768 resolution for clear visuals
- Bezel-free PCAP (Projected Capacitive) touch screen for smooth touch response
- Slim and modern design ideal for space-limited POS counters
- IP65-rated front panel for protection against dust and liquid
- VGA input and USB touch interface for easy integration
- Adjustable tilt angle (15° to 70°) for comfortable viewing
- VESA mount support for flexible installation options
- 270 nits brightness and 500:1 contrast ratio for vivid display quality
- Compatible with major Windows operating systems
- Lightweight (1.69 kg) and durable for long-term commercial use
Product Specifications
Specification | Details |
Display Type | 9.7" TFT LCD (Bezel-free) |
Resolution | 1024 x 768 |
Touch Technology | PCAP (Projected Capacitive) |
Brightness | 270 nits |
Response Time | 20 ms (Rising) / 20 ms (Falling) |
Viewing Angle (U/D/L/R) | 70° / 70° / 70° / 60° |
Input Signal | VGA |
Touch Interface | USB |
Tilt Adjustment | 15° – 70° |
Mounting | VESA Mount Supported |
Colour | Black |
Protection | IP65 Front Panel |
Operating Temperature | 0°C – +50°C |
Storage Temperature | -20°C – +70°C |
Power Supply | 12V DC Power Adapter (18W) |
Dimensions (W x D x H) | 206mm x 244.5mm x 187.5mm |
Weight | 1.69 kg |
Certifications | C-Tick, CE |
Supported OS | Windows XP Pro, POSReady 2009/7, Windows 8.1 Embedded Retail, Windows IoT |
