Description
Posiflex presents the fan-free XP-3312E series as an advanced all-in-one POS terminal. The XP-3312E has been upgraded with the new Intel Pine View 1.8Ghz CPU and uses the latest in memory technology, DDR3 800Mhz SO-DIMM 1GB upgradable to 4 GB.
Features:
- All in one POS Touch System
- Fan Free Design
- Resistive touch screen : 12” LCD 1024 x 768 resolution
- Intel Pine View Dual Core 1.8 GHz CPU and DDR3 memory
- 3” thermal printer with auto cutter
- Fan-free design boasting quiet and anti-dust features
- Aluminium die casting design for efficient cooling
- Special “drop-load” design for easy printer paper roll loading
Features
Attachments
Specifications
|
CPU |
Intel Pine View D525 Dual Core 1.8 Ghz / 1 M Cache CPU |
|
Memory |
DDR3 800 MHz, SO-DIMM socket x 1, max 4 GB, default 1 GB |
|
Storage |
In Australia standard with 32 GB SSD Also Available with HDD or larger SSD on request |
|
LCD |
12" Active Matrix LCD Display |
|
Resolution |
1024 x 768 |
|
LCD Panel Tilt Angle |
14 ~ 55° |
|
Touch Panel |
5-wire Resistive, USB Interface |
|
Connectivity |
3 x RS-232 interfaces; DB9 x2, RJ-45x1 with 5V or 12V support on COM2/COM3 |
|
4 x USB Ports |
|
|
VGA Port for 2nd Display with 12V power for Posiflex Monitor |
|
|
1 Cash Drawer Port (Controls 2 drawers with optional Y-cable) |
|
|
10/100/1000 Ethernet Port |
|
|
Printer |
80 mm Thermal Printer, 150 mm/sec, with Auto Cutter |
|
Sound |
Buzzer only |
|
Power Supply |
External Power Adapter 12V, 120W |
|
Operating environment |
0 °C ~ 40 °C, 20% ~ 90% Relative Humidity |
|
Size (W x D x H) |
325mm x 386.2mm x 298.1mm |
|
Weight |
6.24 Kg |
