Cino F-780 Handsfree Barcode Scanner with SmartStand & Standard USB Cable

Rugged, 41, High Density, Wired, CINO
$199.00
For Special & Volume Pricing - Call +61 2 9090 4610
FBC780BKIT-U
+

Need Help

Choosing a Product
+61 2 9090 4610 Live Chat Email Us
Talk to our technical Expert
price match

Models

Description

The CINO F780 USB Barcode Scanner with Smart Stand (Black) is built to deliver fast, accurate, and reliable scanning in retail, warehouse, and industrial environments. Featuring solid-state linear imaging technology and an ergonomic design, this model offers excellent performance with no moving parts, making it durable and low maintenance.

With a high-performance scan engine capable of up to 500 scans per second, the F780 quickly reads even damaged, low-contrast, or poorly printed barcodes. This scanner supports all major 1D symbologies, including GS1 DataBar, and comes equipped with a sharp red aiming line for precise targeting. The bundled Smart Stand allows for hands-free presentation scanning with automatic mode switching, increasing efficiency at the point of sale or workbench.

The F780 connects via USB and is powered directly from the host device. With multiple scanning modes, a powerful data editing suite (DataWizard), and visual/audible indicators, this scanner is ready to meet the most demanding scanning requirements.

Product Features

  • Solid-State Linear Imager – Durable design with no moving parts for maximum reliability

  • High-Speed Scanning – Up to 500 scans/sec for rapid data capture

  • Smart Stand Included – Enables hands-free operation with auto-switching modes

  • Exceptional Read Accuracy – Reads degraded, smudged, or low-contrast barcodes

  • Supports GS1 DataBar & Stacked Barcodes – Compatible with all common 1D formats

  • Universal USB Interface – Plug-and-play USB HID & Virtual COM support

  • Bright Aiming Line – Sharp 630 nm red LED ensures accurate targeting

  • Versatile Operating Modes – Manual trigger, presentation, flash, and more

  • Robust Design – Survives 50 drops from 1.8m and 10 drops from 2m onto concrete

  • Powerful Software Tools – Includes FuzzyScan PowerTool and programmable DataWizard

Product Specifications

Scan Engine

Solid-State Linear Imaging

Scan Rate

Up to 500 scans per second

Resolution

Minimum 3 mil (Code 39, PCS 0.9)

Light Source

630 nm visible red LED

Depth of Field

Up to 86 cm on 20 mil Code 39

Supported Symbologies

All major 1D, GS1 DataBar, Linear-stacked formats

Interfaces

USB HID, USB Virtual COM, RS232, PS2, Wand Emulation

Indicators

3 LEDs (Power, Good Read, Status), Programmable Beeper

Operating Modes

Toggle, Trigger, Presentation, Flash, Diagnostic, etc.

Drop Resistance

50 drops @ 1.8m and 10 drops @ 2m to concrete

Protection Rating

IP41

ESD Protection

Functional after 15kV air discharge

Operating Temp.

-10°C to 50°C

Storage Temp.

-40°C to 70°C

Humidity

5% to 95%, non-condensing

Ambient Light Immunity

0 to 100,000 lux

Power Supply

5VDC ±10% (USB powered)

Power Consumption

180 mA (operating), 80 mA (standby)

Dimensions (W x D x H)

70.5 x 97.8 x 156.2 mm

Weight

157g (excluding cable)

Certifications

CE, FCC, RoHS, BSMI, EN60825-1

Included

1x FBC780B-U Scanner (USB), 1x FBCUNISTAND-B Smart Stand (Black)

Features

IP Rating:
  • 41
Rugged:
  • Rugged
Scan Range:
  • High Density
Connectivity:
  • Wired
Manufacturer
:
CINO

Attachments

Brochure (f780.pdf, 269 Kb) [Download]

Specification (F-780_Specification.pdf, 56 Kb) [Download]
