Description
The Star TSP743II Serial printer is a high-performance 4-inch thermal printer ideal for retail, hospitality, and industrial environments that require reliable, high-speed printing of receipts, tickets, labels, and barcodes. Featuring a traditional RS-232 serial interface, it’s perfect for integration with legacy POS systems and embedded applications that demand robust, time-tested communication.
With a print speed of 150mm/sec, auto cutter, and wide-format printing support for media up to 112mm wide and 150gsm thick, this printer ensures crisp, clear output at speed. Whether you're printing promotional graphics, shipping labels, or queue tickets, the TSP743II delivers consistent, high-quality results.
It supports ESC/POS™, Star Line and Page Mode, and comes with an advanced Raster Driver for fast True Type processing. This printer also includes “Drop-in & Print” paper loading, and flexible mounting options including vertical desk boot and wall mount.
Product Features
-
RS-232 serial interface – ideal for legacy POS and industrial systems
-
Fast thermal printing – up to 150mm/sec
-
Supports wide-format media – up to 112mm wide, 150gsm stock
-
Auto cutter – reliable guillotine cutter built-in
-
Flexible media handling – supports internal and external rear-feed paper options
-
Multiple mounting options – desktop, vertical, or wall mount
-
ESC/POS™ and Star emulation modes – broad software compatibility
-
Two-colour print capability – with compatible red/black or blue/black paper
-
Includes PS60A-24C power supply
Product Specifications
Print Method | Direct Thermal |
Max Print Width | 104mm (4") |
Max Media Width | 112mm (4.5") |
Media Thickness | Up to 150gsm |
Print Speed | Up to 150mm/sec |
Interface | RS-232 Serial |
Paper Loading | Drop-in & Print |
Media Feed Options | Internal or external rear feed |
Auto Cutter | Built-in guillotine cutter |
Supported Emulations | ESC/POS™, Star Line Mode, Star Page Mode, Raster Drivers |
Printer Dimensions | 180(W) x 213(D) x 148(H) mm |
Mounting Options | Desktop, vertical boot, wall mount |
Power Supply | PS60A-24C (Included) |
Features
- Auto Cutter
- Desktop
- Thermal Print
- Serial
- Grey
- White
- 112mm
