Description
Engineered for the toughest conditions, the Zebra ZQ511 is a high-performance 3-inch mobile direct thermal printer built to withstand demanding environments. Featuring dual wireless connectivity—Bluetooth 4.1 and 802.11ac Wi-Fi—this printer offers the ultimate flexibility for field operations in logistics, public safety, transportation, and retail.
Tested to military-grade (MIL-STD 810G) standards with an IP54 rating, the ZQ511 endures drops, tumbles, dust, and water without a protective case. The powerful 3250 mAh PowerPrecision+ battery keeps your team productive all shift long, while Zebra’s Print DNA suite ensures seamless deployment, management, and ongoing performance.
With support for linerless, tag, receipt, and black mark media, the ZQ511 allows you to print everything from labels and invoices to RFID tags. Its lightweight handheld design and LCD screen make operation effortless—even in the harshest mobile settings.
Product Features
- Ultra-Rugged Mobility – IP54 rated and MIL-STD 810G certified; withstands drops and 1300 tumbles
- Dual Wireless Interfaces – Bluetooth 4.1 (Classic + LE) and fast Wi-Fi 802.11ac for reliable connectivity
- High-Capacity Battery – 3250 mAh battery with Power Smart Print Technology for long-lasting performance
- Print Anywhere, Anytime – Compatible with Android, iOS, and Windows devices
- Linerless & RFID Ready – Supports various media types including linerless labels and RFID tags
- Smart Printing Technology – Automatically adjusts power for optimal print quality and battery efficiency
- Zebra Link-OS & Print DNA – Powerful software tools for easy configuration and remote management
- Lightweight & Compact – Weighs just 630g for superior mobility in the field
- LCD Display with Easy Navigation – On-device controls and screen make printing fast and user-friendly
- 2-Year Warranty – Backed by Zebra’s industry-leading support
Product Specifications
Specification | Details |
Model | ZQ511 (ZQ51-BAW000A-00) |
Print Method | Direct Thermal |
Print Resolution | 203 DPI |
Max Print Speed | 5 IPS (127mm/sec) in Draft Mode |
Max Print Width | 2 inch (72 mm) |
Max Print Length | 990.6 mm |
Media Width | 3 inch (80.01 mm) |
Media Types | Receipt, Tag, Gap, Black Mark, Linerless, RFID |
Roll Diameter | 2 inch (Max. 51 mm) |
Media Thickness | 139.7 µm |
Memory | 512MB RAM |
Processor | 528 MHz ARM |
Battery | 3250 mAh PowerPrecision+ Li-ion (removable, rechargeable) |
Connectivity | Bluetooth 4.1 + LE, Wi-Fi 802.11ac, USB On-The-Go |
Wireless Security | 802.11r fast roaming, WPA2, EAP, PEAP, TLS |
NFC Support | Yes (Passive) |
Display | LCD Display |
Operating System Support | Android, iOS, Windows |
Supported Languages | ZPL, CPCL, ESC/POS, ZBI, XML |
Barcode Support | Full 1D & 2D Symbologies incl. QR Code, Data Matrix, PDF417, MaxiCode |
Ingress Protection | IP54 (IP65 with optional exoskeleton case) |
Drop Rating | 6.6 ft (2 m) drop tested |
Form Factor | Mobile/Handheld |
Dimensions (W x H x D) | 119mm x 61mm x 150mm |
Weight | 630 g |
Warranty | 2-Year Limited Warranty |
Platform Support | Android, iOS, Windows, PC |
