Description
The Citizen CBM-910 is a compact and lightweight 24-column dot matrix mini printer designed for space-constrained applications such as data logging, instrumentation, and field-based receipts. Powered by serial RS232 interface, this palm-sized device offers up to 2.5 lines per second print speed, making it an ideal solution for real-time data output or duplicate record printing.
Its ability to support up to 3-ply printing allows for original and two copies, perfect for transaction confirmations or multi-user records. The 2K print buffer and memory-switch selectable emulations (CBM910 & iDP3110) ensure seamless integration with existing systems.
Fully compatible with the iDP3110 series and equipped with basic LED indicators, the CBM-910 delivers reliable and easy-to-maintain performance in a rugged form factor.
Product Features
-
RS232 Serial interface for legacy and industrial connectivity
-
Fast 2.5 LPS print speed (24-column mode)
-
Supports plain and multi-part bond paper (up to 3-ply)
-
Palm-sized, ultra-compact footprint – ideal for portable and embedded systems
-
CBM910 & iDP3110 emulations – selectable for easy system integration
-
LED indicators for Power, Paper Out, and Error
-
Friction feed mechanism with easy paper roll installation
-
Windows driver support for text-only printing on legacy OS
-
Compatible with various code pages and international character sets
Product Specifications
Printing Method | Serial Impact Dot Matrix |
Print Speed | Up to 2.5 lines/sec (24 col) |
Interface | RS232 (Serial) |
Print Width | 144 dots/line (24 col) / 180 dots/line (40 col) |
Paper Width | 57.5 mm ± 0.5 mm |
Paper Roll Diameter | Max Ø 60.0 mm |
Media Type | Plain or 2/3-ply paper (max 0.13 mm thickness) |
Buffer Memory | 2K bytes / 72 bytes (selectable) |
Character Sets | PC437, PC850, Katakana, WPC1252, international sets |
LED Indicators | Power (Green), Paper (Orange), Error (Red) |
Emulation | CBM910 & iDP3110 |
Dimensions (WxDxH) | 106 x 180 x 88 mm |
Weight | Approx. 0.47 kg |
Power Supply | Optional (7V DC, not included) |
Operating Conditions | 0–40°C, 10–85% RH (non-condensing) |
Reliability | MCBF: 1.5 million lines (24 col) |
Features
- No Auto-Cutter
- Impact
- Serial / RS232
- White
